According to the customer's requirements,
our company can produce CMC with different viscosity and different degree of substitution .
Sinostar(Qingdao) Chemical Co.,Ltd
Tel.: +86 532 8317 1728
PAC & CMC is used in oil drilling fluids, cementing fluids and fracturing fluids. It is mainly used as a tackifier, fluid loss reducer and rheology control agent in drilling fluids; it is used to control fluid viscosity, suspend heavy objects and prevent fluid loss in cementing fluid; it is mainly used to carry filling in fracturing fluid. Objects, prevent fluid loss.
1. Application of CMC in fresh water, seawater and saturated brine:
* It has uniform substitution molecules, low dosage and high pulping rate.
* Good salt and alkali resistance, strong antibacterial performance and easy to use.
* The fluid loss and viscosity-increasing effect are obvious.
* Rheology control and suspension ability.
2. Application of CMC in drilling fluid:
* Protect the drill bit and increase the drilling speed.
* In low-solids and solid-free drilling fluids, the fluid loss can be significantly reduced and the thickness of the cake can be reduced.
* It has a good inhibitory effect on shale hydration.
3. Application of CMC in cementing fluid:
* It can better protect the well wall and prevent fluid from entering the pores and cracks.
* It can better control fluid viscosity, heavy material suspension and prevent fluid loss.
4. Application of CMC in fracturing fluid:
* CMC products are used in fracturing fluids to efficiently carry "fillers" into the fractures of oil wells and establish permeate channels for effective fluid control.
* Enter the oil well structure to reduce fluid loss and reduce pressure drop.
* Ultra-high viscosity products can also replace guar gum, reducing production costs.
Technical Specifications
Petroleum Drilling Grade (CMC)
Model Index | Viscometer dial reading at 600 r/min | Filtrate Loss(ml) | ||
Deionized aqueous solution | 40g/Lsaline solution | Saturated saline solution | ||
CMC-LVT | ≤90 | — | — | ≤10 |
CMC-HVT | ≥30 | ≥30 | ≥30 | ≤10 |
remarks | Comply with GB/T5005-2010 and API-13A standards. |
Petroleum Drilling Grade (PAC)
Model Index | Experimental Method | Apparent Viscosity(mPa.s) | Filtrate Loss(ml) | Loss on Drying(%) | Degree of Substitution(D.S) |
PAC-LV | API-13A | ≤40 | ≤16 | ≤10.0 | ≥0.90 |
PAC-HV | API-13A | ≥50 | ≤23 | ≤10.0 | ≥0.90 |
Remarks | Comply with API-13A standard. |
Petroleum Drilling Grade Ultra-high Viscosity(CMC)
Model Index | Brookfield 1% viscosity(mPa.s) | Degree of Substitution(D.S) | PH Value | Purity(%) | Loss on Drying(%) |
CMC 5000 | 5000~6000 | ≥0.80 | 6.5~8.5 | ≥90 | ≤10.0 |
CMC 6000 | 6000~7000 | ||||
CMC 7000 | 7000~8000 | ||||
Remarks | Comply with API-13A standard. |
Description: According to the customer's requirements, our company can produce PAC&CMC with different viscosity and purity.
